HSS Ground Flute Jobber Drill Set, Imperial, 21 Pieces

General purpose drills for steels, cast steel, grey cast iron, malleable cast iron, nickel brass, aluminium alloy and graphite. Manufactured from High Speed Steel (HSS), each jobber drill is of an industrial quality, with a ground flute and a blue finish. The 21 piece set is supplied in an indexing metal case. The drills have a point angle of 118, a normal helix angle, a standard web thickness, a relief angle of 10-20, a tolerance of diameter of h8 and a tolerance of shank of f11.

Specification

Property	Value
UNSPSC Code	23241634
eCl@ss Code	21010101
Brand	Sherwood
Supplier Part No.	SHR-025-8720K
EAN13 Barcode	5036140003408
Weight Each	0.80 kg
System of Measurement	Inch [txt]
Number of Pieces	21 [#]
Drill Length Type	Standard Length [txt]
Material	High Speed Steel [txt]
Finish/Coating	Black Oxide [txt]
Flute Construction	Ground Flute [txt]
Cutting Direction	Right Hand [txt]
Drill Size Included	1/16; 5/64; 3/32; 7/64; 1/8; 9/64; 5/32; 11/64; 3/16; 13/64; 7/32; 15/64; 1/4; 17/64; 9/32; 19/64; 5/16; 21/64; 11/32; 23/64; 3/8 in
Diameter Range	1/16" to 3/8" by 1/64" Increments [txt]
Case Type	Metal Case [txt]
Standards Met	BS328 : Part 1 DIN 338N & ANSI B94 - 11M [txt]
Maximum Drill Size	3/8 in.
Minimum Drill Size	1/16 in.
Size Increment	1/64 in.

Further Information

Property	Value
Case Type	Metal
Cutting Direction	Right Hand
Drill Length Type	Standard Length
Drill Size Included	1/16in to 3/8in x 1/64in
Finish/Coating	Black Oxide
Flute Construction	Ground Flute
Material	High Speed Steel
Maximum Drill Size	1/2 in.
Minimum Drill Size	1/16 in.
Number of Pieces	21
Size Increment	1/64 in.
Standards Met	ANSI B94-11M; BS 328; DIN 338N
System of Measurement	Inch

Features and Benefits

• Manufactured from High Speed Steel (HSS) for durability

• 21 piece set ensures you have the right sized jobber drill to hand

• Supplied in an indexed metal case for ease of storage and transportation

Contents

• 1 x 1/16in.

• 1 x 5/64in.

• 1 x 3/32in.

• 1 x 7/64in.

• 1 x 1/8in.

• 1 x 9/64in.

• 1 x 5/32in.

• 1 x 11/64in.

• 1 x 3/16in.

• 1 x 13/64in.

• 1 x 7/32in.

• 1 x 15/64in.

• 1 x 1/4in.

• 1 x 17/64in.

• 1 x 9/32in.

• 1 x 19/64in.

• 1 x 5/16in.

• 1 x 21/64in.

• 1 x 11/32in.

• 1 x 23/64in.

• 1 x 3/8in.

Typical Applications

• Suited for drilling steels, cast steel, grey cast iron, malleable cast iron, nickel brass, aluminium alloy and graphite

Standards

• BS328:Part 1

• DIN 338N

• ANSI B94 - 11M
